Completed project: "8.2 m Lime Bucket Elevator"

For the client, we successfully developed and manufactured a bucket elevator for transporting limestone. Incorporating unique technical solutions, the equipment offers exceptional reliability, durability, and resistance to challenging operating conditions.

This project exemplifies our dedication to maintaining high-quality standards and addressing even the most complex customer needs. The bucket elevator meets all the client’s requirements, ensuring efficient and safe material transport, even under the most demanding conditions.

Contact us

Benefits for the Client

Resistance to Extreme Conditions:

• The bucket elevator operates with limestone stones ranging in size from 3-8 cm, which are fed from the kiln at temperatures up to 150°C.
• The materials used in the construction and coating ensure durability in high-temperature environments.

Wear Protection:

• The most heavily loaded components are lined with wear-resistant Hardox 450 steel, 5 mm thick.
• This significantly extends the service life of the equipment.

Sturdy Construction:

• The casing, head, and boot are made from durable 4 mm thick steel, with additional protection from corrosion provided by a heat-resistant enamel coating (up to 600°C).

High Efficiency and Precision:

• The use of the JET THER bucket belt from the French manufacturer STIF ensures stable operation even under intensive loads.
• Welded buckets with reinforcements withstand the high abrasiveness of the material.
