The VIGIBELT TOUCH, an integrated inductive detector activated by physical belt contact with the sensor. These devices offer seamless connectivity, directly linking to a central control area or the hazard monitor M-JET+. Designed for installation outside the elevator leg per pair, each unit comes supplied with gasket and bolts. With a casing opening of ø55 mm on the rising leg and bolt center to center measuring 51×51 mm, installation is secure and straightforward. Each unit is equipped with 2 wires NC/NO for versatile functionality.



VIGIBELT TOUCH

The VIGIBELT TOUCH, an integrated inductive detector activated by physical belt contact with the sensor. These devices offer seamless connectivity, directly linking to a central control area or the hazard monitor M-JET+. Designed for installation outside the elevator leg per pair, each unit comes supplied with gasket and bolts. With a casing opening of ø55 mm on the rising leg and bolt center to center measuring 51×51 mm, installation is secure and straightforward. Each unit is equipped with 2 wires NC/NO for versatile functionality.

Contact us


  • Integrated inductive detector
  • Activated by physical belt contact with the sensor
  • Installed outside the elevator leg per PAIR
  • Supplied with gasket and bolts
  • Casing opening of ø55 mm on the rising leg
  • Bolt center to center : 51×51 mm
  • Bolt ø : M6
  • 2 WIRES NC/NO
  • ATEX 21/20
  • Eligible for the standard 2014/34/UE
  • EN/IEC 60079-0
  • EN/IEC 60079-31
  • IP6X-IEC 60529

  Leaflet_ Belt Alignment Systems _English.pdf

Technical Specifications
