Specifically designed for environments with high pressure or vacuum conditions, VIGILEX VD-HV offers robust protection against pulsations, ensuring safety for equipment and personnel. With its integrated flange and sealing, VIGILEX VD-HV meets safety standards, providing optimal dust protection. Standard burst pressure is 0.1 bar (max. 0.5 bar) at 22°C (72°F).



VIGILEX VD-HV

SINGLE, REINFORCED DOME PANEL

Specifically designed for environments with high pressure or vacuum conditions, VIGILEX VD-HV offers robust protection against pulsations, ensuring safety for equipment and personnel. With its integrated flange and sealing, VIGILEX VD-HV meets safety standards, providing optimal dust protection. Standard burst pressure is 0.1 bar (max. 0.5 bar) at 22°C (72°F).

Utilized in industries such as:

  • Chemical processing;
  • Food processing;
  • Pharmaceuticals;
  • Woodworking and sawmills;
  • Metalworking;
  • Oil and gas;
  • Mining;
  • Power generation.
Contact us


Vacuum resistance: 200-600 mbar; Shape: Flat; Material: Stainless steel, 304 L; Built-in flange made of stainless steel 304 L; Sealing around the entire diameter made of black EPDM rubber (-40°C - +80°C); Internal dimensions: 150 mm × 600 mm; External dimensions: 230 mm × 680 mm; Surface area: 885 cm².

Standard Features:

  • Vacuum resistance: 200-600 mbar;
  • Shape: Flat;
  • Material: Stainless steel, 304 L;
  • Built-in flange made of stainless steel 304 L;
  • Sealing around the entire diameter made of black EPDM rubber (-40°C - +80°C);
  • Internal dimensions: 150 mm × 600 mm;
  • External dimensions: 230 mm × 680 mm;
  • Surface area: 885 cm².

  • Ex II GD;

  • EN 14491;

  • EN 14994;

  • EN 14797;

  • EN 1127.1;

  • EU Type Examination Certificate: INERIS 15ATEX0001X;

  • Quality Certificate: INERIS 08ATEXQ406.


Leaflet_Explosion vent panel_English.pdf

Leaflet_Explosion vent panel_Slovak.pdf

 Explosion Protection Documentation.pdf

 Hazard monitoring system and safety equipment documentation.pdf
